MORE1. FTTH project usable
2. Field installable
3. Insert loss less than 0.3dB
4. Metal V-shape cavity work well in high and low temperature
5. Installation less than 1 minutes
6. Reliable and superior optical performance
1.Telecome network
2.CATV network
3.Ethernet network
4.Optic communication Equipment
Parameters | Specifications | |
Connector Type | SC/LC/FC/ST | |
Dimension | 50mm/55mm/60mm | |
Cable Diameters | 0.9/2.0/3.0mm | |
Fiber Mode | SM/MM | |
Grinding end-face | UPC/APC | |
Insertion Loss | UPC | APC |
≤0.3dB | ≤0.3dB | |
Return Loss | UPC | APC |
≥45dB | ≥50dB | |
Tension Test | ≥100N | |
Operating Temperature | -40℃~+75℃ |
