MORE1.Adaptive single mode fiber
2.Zero delay automatic forwarding
3.Asynchronous transmission, point-to-multipoint operation, RS-485 interface and fiber conversion
4.Automatically detect serial port rate, identify and control data transmission direction
5.Interface provides 1500W surge protection, 15KV static protection
6.Single mode reaches 20-120 km
7.RS-485 supports 32-point polling (can be customized 128 points)
8.Applications: Industrial automation control, access control, card, parking lot and other systems
RS-485 signal | T+, T- |
Fiber optic signal | IN.OUT |
Direction control | Automatically identify and control data transmission direction by using data flow automatic control technology |
Fiber wavelength | 1310nm/1550nm |
Baud rate | 0-115200Kbps, automatic detection of signal rate |
Fiber wavelength | 1310nm/1550nm |
Electric port transmission distance | 1000 meters from RS-485 port |
Load capacity | RS-485 port supports 32 nodes |
Applications | Industrial automation control, access control, card, parking lot and other systems |
