MORE1. Voice Bandwidth: 8KHZ
2. Codec: PCM codec, each voice channel 256Kb / S, in line with ITU-T G.711
3. Signaling Control: Transparent support any in-band signaling, in line with ITU-T G.732
4. Interface communication terminals: ordinary telephone or PBX, PBX (PBX), a public telephone line PSTN network
5. Connection: point-phone hotline, telephone and switch mode
6. Ringing voltage: 75V, ringing frequency: 25HZ / 50Hz (FXS)
7. Impedance: 200Ω + 680Ω || 0.1μF (FXO) ; 200Ω + 560Ω || 0.1μF (FXS)
8. Fiber Interface Type: single-FC type connector
9. Transmission distance: single-mode 0-20KM
Ethernet RJ45 port specifications:
Rate: 10M/100M, full duplex, half duplex fully adaptive
Actual transmission bandwidth: 50Mbps per network port
Protocol: Support IEEE 802.3, IEEE 802.1Q (VLAN)
Physical interface: RJ45, support AUTO-MDIX (cross line straight line adaptive)
Power supply:
Suitable working voltage AC90~260V, DC5V/2A.
US/EU/UK/AU power supply adaptor is available.
Fiber interface | FC interface |
Voice coding | PCM coding, 64Kbps per voice |
Fiber type | Single mode single fiber |
Power supply | External power adapter |
Working voltage | AC90-260V |
Applicable environment | Communication operators, governments, enterprises and institutions |
