MORE1.Provide one SC fiber connector and one UTP connector
2.Fully Complies with IEEE802.3 10Base-T,IEEE802.3u 100Base-TX/IEEE802.3u 100Base-FX,IEEE802.3z 1000Base-FX Standard.
3.Auto-detection of half/full duplex transfer mode for Tx port
4.Auto-negotiation of 10/100/1000Mbps rate and Auto-MDI/MDIX for Tx port
5.Provide switch configuration of half/full duplex transfer mode for Fx port
6.Extend fiber distance up to 20km for singlemode fiber
7.6 LED display for Power, FDX/Col, FX (Link/Act), TX (Link/Act), FX 1000, TX 100
8. Easy-to-view LED indicators provides status to easily monitor network activity
Standard | IEEE802.3 10BASE-T Ethernet IEEE802.3u 100BASE-TX/FX Fast-Ethernet IEEE802.3z/ab 1000BASE-FX/TX 100M-Ethernet IEEE802.3x | ||
RJ-45 Port | Auto-MDI/MDIX | ||
Fiber Port | Fiber Type | Wavelength | Send-Power |
SC | 1310/1550nm | 20dBm(min.) 0dBm(max.) | |
Frequency Offset | ±125,000bps (or ± 100ppm) | ||
MTU | More than 9036 bytes | ||
Dimensions(WxDxH) | 94x71x27mm (External power) | ||
Input Voltage | DC5V1A( External power input : AC100V-AC240V/50-60HZ ) | ||
OperationTemperature | 0°C~70°C | ||
Store Temperature | -40°C~85°C | ||
Humidity | 5%~95% non-condensing | ||
Weight | 0.3kg/Piece (External Power) |
